Fishfinder Gps Lowrance Elite Fs 9

Name: FISHFINDER GPS LOWRANCE ELITE FS 9
Brand: Lowrance
SKU: 219039

Read more-Product description

From 1004.50€

Recommended retail price : €1351.90

Pay it in 3 or 4 interest-free payments

20 days for returns

Models & specificities

Descriptive

Reviews

Models & specificities Descriptive Reviews

Models & specificities

Back to menu

Reference

Price inc VAT

Shipping

Frequency (kHz)

Transducer

Shipping

Price inc VAT

000-15693-001

€1004.50

Shipped within

24h

50/83/200/455/800

Avec Sonde Active Imaging 3/1

Shipped within

24h

€1004.50

000-15706-001

€1039.50

Models & specificities Descriptive Reviews

Descriptive

Back to menu

Function	Value
Screen size	9 inches
Touch screen	yes
2D classic	yes
Down View	yes
Side View	yes
Chirp	yes
Gps	yes
Bathymetry	yes
Card reader	yes
Live	yes with optional probe
Network	yes

*fine details and options may be indicated in the full description, do not hesitate to delve into it or ask for advice.

Targeting fish has never been easier.

The new LOWRANCE Elite FS (Fishing System) 9 sounder with ACTIVE IMAGING probe gives you access to the 2D CHIRP sonar mode, HDI DownScan Imaging™ mode (Vertical scanned view of the bottom) and SideScan Active Imaging 3-in-1 mode (side scanned view of the bottom) as well as a full range of additional detection tools, including the optional real-time ActiveTarget probe and compatibility with a wide choice of cartography, to help you get the most out of each moment spent on the water.

The Elite Fishing System (FS) 9 with 500w power combines the power of the latest and proven Lowrance detection tools and structures with a more affordable, easier to use and install screen. From integrated support for the optional ActiveTarget feature and ultra-high resolution technology with Lowrance CHIRP sounder and DownScan Imaging, to compatibility with a wide choice of cartography options, the Elite FS gives you all the tools you need to find and catch more fish.

Find more fish with the Lowrance Elite FS sounder
With the Elite FS Active Imaging 3-in-1 sounder, featuring CHIRP, SideScan and DownScan technologies with FishReveal, you can view structures and covered areas with a high level of detail and a range unmatched by any other bottom imaging technology. Take advantage of the best sonar CHIRP and DownScan Imaging technologies on the same screen with FishReveal, a exclusive Lowrance feature that allows you to easily identify fish among structures and covered areas on very detailed DownScan images.

A multitude of map options
The Elite FS screens include a basic worldwide cartographic background without details and are compatible with a wide choice of mapping options, including C-MAP, Navionics and more.

Technical features
• 9’’ multitouch high resolution touchscreen
• Supports probe frequencies 50, 83, 200, 455 and 800 kHz
• Wireless, NMEA 2000 and Ethernet connectivities integrated
• Full control via touchscreen of Power Pole anchors and Ghost front motor
• Full networking with Ethernet network pin (requires a LOWRANCE ETHEXT Ethernet cable)
• Easy to use and install
• Compatible with the optional ActiveTarget probe reference = LW000-15593-000
• Includes a basic worldwide cartographic background without details, and is compatible with a wide choice of map options, including C-MAP, Navionics and more
• Compatible with C-MAP's Easy Routing features and Navionics Autourouting
• Real time map display on the screen with C-MAP Genesis Live

In Option
• Active Target probe reference = LW000-15593-00

In the box
• Elite Fs 9’’ handset screen
• Screen fixing bracket and knobs
• Comes with a plastic screen protection cover
• ACTIVE IMAGING 3/1 Rear Table Transducer reference: LW000-14489-001 for the sonar model reference LW000-15693-001
• Transducer bracket
• 12Vdc power cord
• French user manual on CD-ROM.

User manual
