Models & specificitiesDescriptiveReviewsA questionBesoin de formation
Models & specificities
Back to menu
Reference
Price inc VAT
Shipping
Weigth (kg)
Voltage (V)
Amperage max.
Dimensions (mm)
Shipping
Price inc VAT
BSR-VALG2-1250
£826.84
£734.97Offer subject to availability
Shipped within
24h
8
12
50
318 x 257 x 152
Shipped within
24h
£826.84
£734.97Offer subject to availability
Models & specificitiesDescriptiveReviewsA questionBesoin de formation
Descriptive
Back to menu
VL1250 - Lithium battery in the form of a 12V 50A case supplied with charger.
The new range of lithium batteries is packaged as a waterproof IP68/69 transport case.
NEW Generation 2: Discharge indicator providing additional information instantly:
Developed for intensive use in navigation and specially designed to power Minn Kota electric motors with integrated 20amp transducer output. Focus on your fishing session, the BSR battery takes care of your engine!
The case is equipped with a motor power output + an additional regulated 12-volt 20A waterproof output for the transducer(s) and electronic accessories. LED screen displaying the battery temperature, its voltage, its charge rate, low voltage alarm.
The NANUK's integrated auto-pressure valve equalizes this atmospheric pressure difference. Using state-of-the-art technology, the micro-vent allows air to pass while preventing water from penetrating.
The 12v charger is equipped with the ip68/69 – salt screw connector.
BSR battery features: • Type: 12v 50Ah • Voltage: 12.8v • Technology: Lifep04 / 640 wh • Discharge cycle: 2000-3000 at 100% • Dimensions (mm): 318x257x152mm • Net weight: 8.00 Kg • Structure: Case • Transducer: Quick waterproof transducer plug - 20A • Connectors: Quick waterproof plug 60A • Resistant to shock – vibration – sand – sea • Protection by BMS integrated 60A, Breaker 60A, INOX screws. • Discharge: 2c or 100A max • Charge: 1c max, up to 50A • Cycle: 2000 at 100% dod • Charging voltage: 14.6v • Maximum discharge voltage: 10.50v • Ideal charging temperature: 0 to 45 °C • Possible discharge temperature: -25 to +55°c • Explosion proof • Waterproof – IP68/69 • Fire standard: UL94 VO • Resistant to shock – vibration – sand – sea
Transducer plug supplied ip68/69 – salt screw
60A Motor Connector / ip68/69 – Salt Fire Standard UL94VO to weld or crimp.
Customer service in France 4-Year Warranty
In the box: • 1 12v 50Ah Battery • 1 12v 10A charger • 1 transducer / charger screw connector IP68/69 • 1 Engine connector to weld 60A / ip67
Additional plugs optional: - Additional male power plug for Motor ref BSR-PRMOT - Additional male power plug for Transducer ref BSR-PRSOND
